10kA DC MCB for DC power distribution system

OSDM-80DC series DC miniature circuit breaker (hereinafter referred to as circuit breaker) is suitable for lines with rated current of 125A

● Standard: IEC60947-2
● Type of trip: Thermo-magnetic
● Rated current: 80,100,125A
● Rated voltage: 1P(250VDC), 2P(500VDC), 4P(1000VDC)
● Number of poles: 1P,2P,4P
● Rated short-circuit breaking capacity: 10kA
●Magnetic release characteristic: (8-12) x In
● Ambient air temperature: -5...+40 ºC
● Connection: According to the wiring diagram
● Certificates: CE, CB

Send Inquiry Live Chat

Product Details
Packing & Delivery
FAQs

Porduct Overview

OSDM-80DC series DC miniature circuit breaker (hereinafter referred to as circuit breaker) is suitable for lines with rated current of 125A and below DC rated voltage of 250V or 500V and 1000V. lt is used for overloading and short-circuit protection of facilities and electrical equipment of DC power distribution system, and can be widely used in electric power, post and telecommunications, communication, industrial and mining enterprises and other industries. This product meets the requirements of IEC60947-2.

Advantages

Protection functions: overload, short circuit
Rated short circuit breaking capacity icu up to 10kA
Non-polarity, easy wiring
Rated current up to 125A
Rated voltage up to 1000V
Designed for PV, energy storage and other dc applications

Technical parameters

Technical Data

Standard	IEC/EN60947-2
Protection	Overcurrent and short circuit
Type of trip	Thermo-magnetic
No. of poles	1P,2P,4P
Rated currents (In)	80,100,125A
Rated voltage (Ue)	1P(250VDC), 2P(500VDC), 4P(1000VDC)
Rated insulation voltage (Ui)	500V
Rated breaking capacity	10,000A
Rated impulse withstand voltage (1.2/50) Uimp	4kV
Dielectric test voltage at Ind. Freq. for 1 min	3kV
Thermal release characteristic	(1.05-1.30) x In
Magnetic release characteristic	(8-12) x In
Electrical life	4,000 Cycles
Mechanical life	10,000 Cycles
Contact position indicator	Yes
Protection degree	IP20
Ambient temperature	-5℃ to +40℃, Max. 95% humidity
Terminal connection type	Cable/Pin-type busbar/Fork-type busbar
Max. terminal size for cable	35mm²
Max. tightening torque	2.5N.m
Installation	Mounting on 35mm DIN rail
Connection	According to the wiring diagram

Dimensions

Circuit Diagram

Overall and Installation Dimension(mm)
